Automotive 8-Channel SPI Gate Driver Half-Bridge Smart Gate Driver for AEC-Q100 Grade 1 Designs

DRV8718SQRVJRQ1 automotive 8-channel half-bridge gate driver in VQFN 56 · E-MAIL: sales@bluetotech.com

Automotive 40 V, 8-Channel Half-Bridge Smart Gate Driver

The DRV8718SQRVJRQ1 is a Texas Instruments automotive multi-channel smart half-bridge gate driver that drives eight external N-channel MOSFET half-bridges (four full bridges) from a SPI-controlled, 4.9 V to 37 V rated supply. Because the power FETs are external, the same driver covers a wide range of load currents, from small valve solenoids to high-current seat and pump motors.

Each channel has a smart multi-stage gate drive with adjustable slew rate and adaptive propagation delay control, which keeps EMI and switching losses balanced without changing the external FETs. Inline current sense amplifiers in the source path enable phase current measurement without high-side shunt resistors, and open-load detection plus SPI diagnostics simplify safety monitoring in AEC-Q100 grade 1 automotive designs.

Key Features

• 8 half-bridge channels, configurable as 4 full bridges or 8 independent half-bridges
• 4.9 V to 37 V operating range with 40 V absolute maximum rating
• SPI control interface plus independent 1/2-bridge, PH/EN and PWM control modes
• Inline current sense amplifier with wide common mode range
• Smart multi-stage gate drive with adjustable slew rate and adaptive propagation delay
• Tripler charge pump for 100% PWM duty cycle, 50 µA to 62 mA peak source current
• Open-load detection, detailed SPI fault reporting, 5 µA sleep current
• AEC-Q100 grade 1 qualified, -40 °C to +125 °C, VQFN (RVJ) 56 of 8 x 8 mm

Technical Specifications

Typical Applications

Automotive body control modules, multi-channel valve and solenoid drivers, seat, window and liftgate motor control, HVAC flap and pump actuators, brushed DC and stepper motor drive, and multi-axis positioning stages that need SPI diagnostics and inline current sensing.

Stock, Packing and Quotation

DRV8718SQRVJRQ1 is in stock in original TI packing with 26+ date codes and full traceability. Orders ship in factory reel with desiccant and humidity indicator card, packed in export cartons.

Send your BOM or target quantity and price, lead time and shipping cost are confirmed the same working day. Samples and evaluation quantities are available on request.

E-MAIL: sales@bluetotech.com
Please quote the exact part number and your required quantity when you inquire. Minimum order quantity: 10 pieces.
