16-Bit 100ksps Sampling ADC with Bipolar 10V Input, Analog-to-Digital Converter in SSOP-28

LTC1605IG#PBF 16-bit 100ksps sampling ADC in SSOP-28 · E-MAIL: sales@bluetotech.com

16-Bit 100ksps Sampling ADC with Bipolar 10V Inputs

The LTC1605IG#PBF is a 16-bit sampling analog-to-digital converter from Analog Devices (Linear Technology) that samples at 100 ksps and accepts true bipolar plus/minus 10 V inputs directly. The trimmed input range means a plus/minus 10 V industrial signal connects without a level shifting amplifier, which removes offset and gain error sources from the front end of an instrumentation or ATE channel.

Conversion runs from a single 5 V supply and draws only 55 mW, while signal-to-noise ratio reaches 86 dB, so the full 16-bit resolution is usable in practice rather than on paper. Results are read over a parallel interface that connects directly to a DSP, FPGA or microcontroller bus, and the SSOP-28 package keeps the converter close to the sensor on dense boards.

Key Features

• 16-bit resolution, 100 ksps throughput, no missing codes
• True bipolar plus/minus 10 V input range, factory trimmed
• Single 5 V supply, 55 mW power dissipation
• 86 dB signal-to-noise ratio for full 16-bit accuracy
• Parallel output interface for direct DSP, FPGA or MCU connection
• Sample-and-hold with 1.5 microsecond acquisition time
• SSOP-28 package for high density instrumentation boards
• Ideal for industrial data acquisition, ATE and vibration analysis

Technical Specifications

Typical Applications

Industrial data acquisition systems, automatic test equipment, vibration and strain measurement, power quality analysers, medical and laboratory instruments, and any channel that needs 16-bit accuracy with a plus/minus 10 V industrial input.

Stock, Packing and Quotation

LTC1605IG#PBF is in stock in original ADI packing with 23+ date codes and full traceability. Orders ship in factory tubes with desiccant, packed in export cartons.

Send your BOM or target quantity and price, lead time and shipping cost are confirmed the same working day. Samples can be arranged for qualification testing.

E-MAIL: sales@bluetotech.com
Please quote the exact part number and your required quantity when you inquire. Minimum order quantity: 10 pieces.
