16-Bit 200ksps ADC Analog-to-Digital Converter with SPI Interface for Precision Industrial Data Acquisition
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Manufacturer: | Analog Devices (Maxim) | Part Number: | MAX1162BEUB+T |
|---|---|---|---|
| Package / Case: | 10-pin MSOP (uMAX) | Resolution: | 16 Bit |
| Sampling Rate: | 200 Ksps | Analog Supply: | +5 V |
| Digital Supply: | +2.7 V To +5.25 V | Input Range: | 0 V To VREF |
| Input Bandwidth: | 4 MHz | Interface: | SPI, QSPI, MICROWIRE |
| Supply Current: | 2.75 MA At 200 Ksps, 0.1 UA Shutdown | Date Code: | 19+ |
| Mounting Type: | Surface Mount | Stock Status: | In Stock |
| Highlight: | 16-Bit ADC,200ksps Analog-to-Digital Converter,SPI Interface ADC |
||
MAX1162BEUB+T 16-bit 200ksps ADC in 10-pin MSOP · E-MAIL: sales@bluetotech.com
16-Bit, 200ksps ADC in a 10-Pin MSOP
The MAX1162BEUB+T is a 16-bit successive-approximation ADC from Analog Devices (Maxim) that samples at up to 200ksps from a single +5V analog supply. A separate digital supply from +2.7V to +5.25V lets it interface directly to 3.3V logic without level shifters, and the 10-pin MSOP footprint keeps the converter close to the sensor.
The internal track-and-hold amplifier accepts signals up to a 4MHz input bandwidth over the 0 to VREF range. Automatic power-down and a fast 1.1us wake-up bring supply current down to 140uA at 10ksps and 0.1uA in shutdown, which suits battery-powered instruments and multiplexed industrial front ends.
Key Features
- 16-bit resolution with no missing codes
- 200ksps throughput from a +5V single analog supply
- Adjustable logic level from +2.7V to +5.25V for direct 3.3V interfacing
- Input voltage range 0 to VREF with internal track and hold
- 4MHz input bandwidth, SPI/QSPI/MICROWIRE compatible serial interface
- Low power: 2.75mA at 200ksps, 140uA at 10ksps, 0.1uA in power-down
- Fast 1.1us wake-up from shutdown
- Small 10-pin MSOP package
Technical Specifications
| Manufacturer | Analog Devices (Maxim) |
| Part Number | MAX1162BEUB+T |
| Package / Case | 10-pin MSOP (uMAX) |
| Resolution | 16 bit |
| Sampling Rate | 200 ksps |
| Analog Supply | +5 V single supply |
| Digital Supply | +2.7 V to +5.25 V, adjustable logic level |
| Input Range | 0 V to VREF |
| Input Bandwidth | 4 MHz |
| Interface | SPI, QSPI, MICROWIRE compatible |
| Supply Current | 2.75 mA at 200 ksps, 0.1 uA shutdown |
| Date Code | 19+ |
| Mounting Type | Surface mount |
Typical Applications
Industrial process control and PLC analog inputs, portable and battery-powered instruments, data acquisition modules, transducer and sensor signal chains, medical monitors, and any multiplexed 16-bit front end that needs a small SPI ADC.
Stock, Packing and Quotation
MAX1162BEUB+T is in stock in original packing with 19+ date codes and full traceability. Orders ship in factory tape and reel with desiccant, packed in export cartons.
Send your BOM or target quantity and price, lead time and shipping cost are confirmed the same working day. Samples can be arranged for qualification testing.
E-MAIL: sales@bluetotech.com
Please quote the exact part number and your required quantity when you inquire. Minimum order quantity: 10 pieces.
