8-Channel 200kSPS Automotive Qualified ADC Analog-to-Digital Converter TSSOP-20 SPI
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Manufacturer: | Analog Devices | Part Number: | AD7927WYRUZ-REEL7 |
|---|---|---|---|
| Package / Case: | TSSOP-20 | Resolution: | 12 Bit |
| Sampling Rate: | 200 KSPS | Number Of Inputs: | 8 Single-ended With Sequencer |
| Supply Voltage (AVDD): | 2.7 V To 5.25 V | Power: | 3.6 MW Max At 200 KSPS On 3 V |
| SINAD: | 70 DB Min At 50 KHz | Interface: | SPI, QSPI, MICROWIRE |
| Shutdown Current: | 0.5 UA Max | Qualification: | Automotive Qualified |
| Date Code: | 19+ | Mounting Type: | Surface Mount |
| Stock Status: | In Stock | ||
| Highlight: | 8-Channel ADC,200kSPS Analog-to-Digital Converter,Automotive Qualified ADC |
||
AD7927WYRUZ-REEL7 8-channel 12-bit 200kSPS ADC in TSSOP-20 · E-MAIL: sales@bluetotech.com
8-Channel, 200kSPS, 12-Bit ADC with On-Chip Sequencer
The AD7927WYRUZ-REEL7 is a 12-bit, 8-channel successive-approximation ADC from Analog Devices that converts at up to 200kSPS from a single 2.7V to 5.25V supply. Eight single-ended inputs with a built-in sequencer let one converter scan a full sensor bank without external multiplexer control from the host.
Power scales with throughput: 3.6mW maximum at 200kSPS on a 3V rail and 7.5mW on 5V, with a 0.5uA shutdown mode between conversions. The part is qualified for automotive applications, which makes it suitable for under-hood and body electronics as well as general industrial data acquisition.
Key Features
- 8 single-ended inputs with on-chip channel sequencer
- 12-bit resolution, 200kSPS throughput, no pipeline delay
- Single supply from AVDD 2.7V to 5.25V
- Low power: 3.6mW max at 200kSPS on 3V, 7.5mW on 5V
- Wide input bandwidth with 70dB minimum SINAD at 50kHz input
- SPI, QSPI, MICROWIRE and DSP compatible serial interface
- Shutdown mode 0.5uA maximum
- 20-lead TSSOP, qualified for automotive applications
Technical Specifications
| Manufacturer | Analog Devices |
| Part Number | AD7927WYRUZ-REEL7 |
| Package / Case | TSSOP-20 |
| Resolution | 12 bit |
| Sampling Rate | 200 kSPS |
| Number of Inputs | 8 single-ended with sequencer |
| Supply Voltage (AVDD) | 2.7 V to 5.25 V |
| Power | 3.6 mW max at 200 kSPS on 3 V |
| SINAD | 70 dB min at 50 kHz |
| Interface | SPI, QSPI, MICROWIRE, DSP compatible |
| Shutdown Current | 0.5 uA max |
| Qualification | Automotive qualified |
| Date Code | 19+ |
| Mounting Type | Surface mount |
Typical Applications
Automotive sensor and body control modules, industrial PLC and process control inputs, multi-channel data acquisition cards, instrumentation and panel meters, motor and power monitoring front ends, and battery or supply rail monitoring.
Stock, Packing and Quotation
AD7927WYRUZ-REEL7 is in stock in original ADI packing with 19+ date codes and full traceability. Orders ship in factory reel with desiccant and humidity indicator card, packed in export cartons.
Send your BOM or target quantity and price, lead time and shipping cost are confirmed the same working day. Samples can be arranged for qualification testing.
E-MAIL: sales@bluetotech.com
Please quote the exact part number and your required quantity when you inquire. Minimum order quantity: 10 pieces.
